| Type | Transformer balanced |
| Impedance | |
| Balanced | 20k |
| Unbalanced | 10k |
| Output | |
| Type | Transformer balanced |
| Min. Load impedence | 600 |
| Source impedance | |
| Max. Level | +22dBu |
| Performance | |
| Frequency response | ±0.5dB(20Hz-20kHz) |
| Distortion (@ +4dBm) | <0.01% @ 1kHz |
| Equivalent input noise | <-90dBu (20Hz-20kHz unweighted) |
| Channel separation | >75dB @ 1kHz |
| Overload indicator | +19dBu |
| Level Control | +6dB to - ∞ |
| Filters | |
| Centre frequencies | 2 x 30 |
| ISO | 25Hz - 20kHz 1/3 octave |
| Tolerance | ±5% |
| Maximum boost/cut | ±6/12dB |
| High pass filter | 18dB/octave - 3dB @ 30Hz |
| Low pass filter | 18dB/octave - 3dB @ 20Hz |
| Power Requirements | |
| Voltage | 110/120/220/240V 50/60Hz |
| Consumption | <15VA |
| Weight | |
| Nett | 5Kg |
| Shipping | 6Kg |
| Dimensions | |
| Width | 482mm (19”) |
| Depth | 205mm (8”) |
| Height | 133mm (51/4”) |
| Terminations | |
| Input | 3 pin XLR |
| Output | 3 pin XLR |
| Power | 3 pin ICE |
