Nominal diameter |
380 mm 15 in |
|
Nominal impedance |
8 Ohm |
|
Minimum impedance |
6.3 ohm |
|
Power capacity |
500 W AES |
|
Program power |
1000W |
|
Sensitivity |
98 dB 1 W / 1 m @ ZN |
|
Frequency range |
30-4000 Hz |
|
Recommended enclosure volume |
40 / 150 l / 1.4 / 5.3 ft³ |
|
Voice coil diameter |
101.6 mm 4 in |
|
BI factor |
23 N/A |
|
Moving mass |
0.116kg |
|
Voice coil length 20,5 mm |
|
Air gap height |
10 mm |
|
Xdamage |
46 mm |
THIELE SMALL PARAMETERS
|
Fs |
23 Hz |
|
Re |
6.1 ohm |
|
Qms |
5.5 |
|
Qes |
0.22 |
|
Qts |
0.21 |
|
Vas |
360l |
|
Cms |
330 µm / N |
|
Rms |
3.4 kg / s |
|
Efficiency % |
2,7% |
|
Sd |
0.088 m² |
|
Xmax |
8 mm |
|
Vd |
704 cm³ |
|
Le @1 kHz |
1.5 mH |
