Nominal diameter |
460 mm 18 in |
|
Nominal impedance |
8 Ohm |
|
Minimum impedance |
7 ohm |
|
Power capacity |
1600 W AES |
|
Program power |
3200 W |
|
Sensitivity |
96 dB 1 W/1 m @ ZN |
|
Frequency range |
35-1000 Hz |
|
Voice coil diameter |
101.6 mm 4 in |
|
BL factor |
24.5 N/A |
|
Moving mass |
0.229 kg |
|
Winding length |
35 mm |
|
Air gap height |
14 mm |
|
Xdamage pp |
65 mm |
THIELE SMALL PARAMETERS
|
Fs |
33 Hz |
|
Re |
5.8 ohm |
|
Qms |
11.4 |
|
Qes |
0.45 |
|
Qts |
0.43 |
|
Vas |
231 l |
|
Cms |
104 µm / N |
|
Rms |
4.1 kg / s |
|
Efficiency % |
1.7 |
|
Sd |
0.1255 m² |
|
Xmax |
14.5 mm |
|
Vd |
1820 cm³ |
|
Le @1 kHz |
1.9 mH |
CONSTRUCTIVE DETAILS
|
Depth |
236 mm 9.3 in |
|
Net weight |
9.5 kg 20.9 lb |
|
Total weight |
10.8 kg 23.8 lb |
|
Magnet |
Neodymium |
